STS-100: Canadarm2 takes flight

Canadarm2 catches a visiting SpaceX Dragon cargo capsule at the International Space Station. (Credit: NASA)

Canadarm2 catches a visiting SpaceX Dragon cargo capsule at the International Space Station. (Credit: NASA)

Special note: Tune into York Universe for a two-part special looking at STS-100 and the installation of Canadarm2, featuring interviews with the Canadian Space Agency Flight Controller Supervisor Mathieu Caron and Canadian Astronaut Chris Hadfield. Part one of the special airs April 27 and part two airs on May 4, 2015.

York Universe airs live every Monday at 9:00 p.m. ET (1:00 a.m. UTC, Tuesday) on Astronomy.FM – the voice of astronomy on the internet.


STS-100 was a flight of the Space Shuttle Endeavour from April 19-May 1, 2001 (11 days, 21 hours). The flight was commanded by Kent Rominger, piloted by Jeffrey Ashby, and carried five Mission Specialists: Chris Hadfield (CSA), John Phillips, Scott Parazynski, Umberto Guidoni (ESA), and Yuri Lonchakov (RKA).

It’s been suggested this flight was the pinnacle of Canada in space. And this is arguably true, though there have been several other significant Canadian missions to be sure: the launch of Alouette or Chris Hadfield commanding the ISS, to name only two possibilities. The point of this though is to highlight the importance of STS-100 to Canada and the international space community, rather than argue about which the ‘most’ important contribution is.

The primary goal of STS-100 was to deliver and install to the fledgling International Space Station the new robotic arm, Canadarm2. Along to head this effort was Canadian Space Agency Astronaut Chris Hadfield – and installing the next generation arm required two spacewalks for Hadfield and Parazynski. Hadfield’s EVA on STS-100 was also the first spacewalk in history for a Canadian.

In total, the pair spent 14 hours, 50 minutes ‘outside’ in order to accomplish the goal.

Chris Hadfield on the first Canadian spacewalk on April 22, 2001. (Credit: NASA)

Chris Hadfield on the first Canadian spacewalk on April 22, 2001. (Credit: NASA)

Canadarm2 is 17.6 m (58 feet) long and has seven powered joints. It weighs 1,800 kg and is capable of moving payloads up to 116,000 kg!

It can be controlled from on board the ISS, or remotely from robotics stations at mission control centres around the world, including the CSA’s John. H Chapman Space Centre just outside Montreal.


Canadarm2 was (of course) based on the design of the Space Shuttle Canadarm, first launched in 1981 on STS-2. Canadarm (1) was 15.2 m (50 feet) long. In all five Shuttle Canadarm’s were built, with a redesign in the 1990’s to increase the arms’ ability to move larger objects to support ISS construction (the strength was increased by an order of magnitude, going from 332.5 kg up to 3,293 kg).

Towards the end of STS-100 once Hadfield and Parazynski had completed its installation, Canadarm2 was powered up for the first time in space on April 28, 2001.

And Canadarm2’s first objective? Link up with the Shuttle Canadarm to return the new arms cargo palette to Endeavour’s cargo bay. It was a remarkable Canadian robotic handshake in space.

The Canadian Handshake: Canadarm and Canadarm2 connect in space for the first time on April 28, 2001. (Credit: NASA)

The Canadian Handshake: Canadarm and Canadarm2 connect in space for the first time on April 28, 2001. (Credit: NASA)

Since then, Canadarm2 has been invaluable in both the construction and operations of the ISS – including catching visiting cargo spacecraft and docking them to the station on a regular basis. It is not an exaggeration to say that the ISS would not have been able to have been constructed without Canadarm2.

Look back at STS-100 with the astronauts who flew the mission:

Canadarm2 is able to move itself around on the ISS by making use of either the Mobile Transporter (a rail structure that runs the length of the ISS) or by moving end-over-end, sort of like an inch-worm, and grappling Power Data Grapple Fixtures that provide a physical connection as well as electrical and data connectivity. With these two methods within arm’s reach, Canadarm2 is able to be work from any location along the ISS’s main truss.

Canadarm2 has also since been joined on the ISS by a second Canadian robotic handyman: DEXTRE, which arrived in March 2008 on STS-123 (read more about DEXTRE here).

With these innovations – and others – Canada is making a name for being a leader in space robotics, and STS-100 surely cemented that reputation.

Canadian space robots: DEXTRE catches a ride at the end of Canadarm2 on the ISS. (Credit: NASA)

Canadian space robots: DEXTRE catches a ride at the end of Canadarm2 on the ISS. (Credit: NASA)

Cool Applet showing the surface of Vesta

Over the past few years, before heading to Ceres in a landmark rendezvous in March of 2015, the Dawn spacecraft mapped out the surface of the largest asteroid, Vesta.   This amazing little applet shows the entire surface of the asteroid with some craters highlighted.  Called Vestatrek, it shows all kinds of data from Dawn, […]

A picture is worth 1000 words or a Billion Stars

Some pictures speak volumes, and some have interesting hidden details that we don’t always see from the outset.  A stunning photo of the Milky Way from Taiwan shows more than meets the eye. At first glance, you might notice the fascinating shot of the Milky Way, and you may even pick up on the fact […]

Happy 25th Birthday Hubble!

Today is the day, 25 years ago, that the Hubble space telescope launched from the Kennedy Space Centre aboard the Space Shuttle Discovery.  The world had high hopes for Hubble, but we had no idea what great treasures were waiting for us in the depths of the cosmos.  No piece of technology in human history […]

Celebrate the Hubble Space Telescope’s 25 years in space – #Hubble25

The Hubble Space Telescope was launched on April 24, 1990 – a quarter century ago! Since then (admittedly with a couple hiccups) it has been peering deeper into the cosmos than any telescope in human history. We have learned more about the origin of the universe, the makeup of galaxies, and distant worlds though Hubble’s eye – and with great effort from many researchers around the world.

Hubble is a joint project of NASA and the European Space Agency (ESA). Hubble weighs in at 11,000 kg, is 13.2 m by 4.2 m, and has a 2.4 m diameter primary mirror. Hubble coasts along in orbit at a cool 25,600 km/h at an altitude of 555 km above the surface of the Earth.

Hubble’s direct successor in space will be the James Webb Space Telescope, set for launch in 2018 – though Hubble is still expected to be in operation. Numerous next generation ground-based telescopes will also come online between 2020-2025, including the Thirty Meter Telescope (read in detail about TMT here).

To celebrate Hubble’s 25th birthday, the Hubble team released a new image from Hubble today: an image of the cluster Westerlund 2 and its surroundings.

This NASA/ESA Hubble Space Telescope image of the cluster Westerlund 2 and its surroundings has been released to celebrate Hubble’s 25th year in orbit and a quarter of a century of new discoveries, stunning images and outstanding science. The image’s central region, containing the star cluster, blends visible-light data taken by the Advanced Camera for Surveys and near-infrared exposures taken by the Wide Field Camera 3. The surrounding region is composed of visible-light observations taken by the Advanced Camera for Surveys. (Credit: NASA, ESA, the Hubble Heritage Team (STScI/AURA), A. Nota (ESA/STScI), and the Westerlund 2 Science Team)

This NASA/ESA Hubble Space Telescope image of the cluster Westerlund 2 and its surroundings has been released to celebrate Hubble’s 25th year in orbit and a quarter of a century of new discoveries, stunning images and outstanding science. The image’s central region, containing the star cluster, blends visible-light data taken by the Advanced Camera for Surveys and near-infrared exposures taken by the Wide Field Camera 3. The surrounding region is composed of visible-light observations taken by the Advanced Camera for Surveys. (Credit: NASA, ESA, the Hubble Heritage Team (STScI/AURA), A. Nota (ESA/STScI), and the Westerlund 2 Science Team)

Even after 25 years, Hubble continues to impress with its images and scientific discovery to this day. For instance, Hubble data recently contributed to strengthening the hypothesis that Jupiter’s largest moon Ganymede has a massive subsurface ocean of liquid water.

One of the best videos I’ve been able to find that offers an overview of the Hubble mission is from the telescope’s 15th birthday, back on April 24, 2005. It’s worth a watch, and of course add another decade (!!) worth of discovery on top:

On top of several physical celebrations going on around the world for the occasion of #Hubble25, there is also a lot of great content on social media:



And remember a couple years ago when the Defense Department donated two better-than-Hubble space telescopes to NASA? Read here for that one.

It’s a big universe and we need all the eyes we can get to help unravel its mysteries.

The Canadarm on board The Space Shuttle Discovery releases Hubble in April 1990. (Credit: NASA/ESA)

The Canadarm on board The Space Shuttle Discovery releases Hubble in April 1990. (Credit: NASA/ESA)

And a fun (patriotic Canadian) fact: the last piece of hardware to come into physical contact with Hubble was the Canadarm on board the Space Shuttle Atlantis on mission STS-125 in May 2009, following the conclusion of Hubble Servicing Mission 4, the last mission to visit the telescope:

Canadarm lifts the Hubble Space Telescope out of the payload bay of Atlantis, moments before it is released into space following the successful repair mission of STS-125. (Credit: NASA)

Canadarm lifts the Hubble Space Telescope out of the payload bay of Atlantis, moments before it is released into space following the successful repair mission of STS-125. (Credit: NASA)
